Wholesale OEM China Aluminum Stepless Shear Bolt Connector

Short Description:

Terminals, connectors and cable lugs using screw technology have been on the advance for years, and with good reason. The special design feature of the shear bolt connectors is that there are no predetermined break points in the thread. This provides for optimal load bearing capacity for each range of cross sections. The bolt always breaks at the surface of the clamp body, so there are no protrusions and nothing has to be filed down to make the sleeve fit. Fitting requires a simple tool – literally with a flick of the wrist. Offering a large clamping range, shear bolt connectors feature a compact design with rounded edges and flat transitions suitable for slide-on and shrink sleeves

Send email to us

Product Detail

Product Tags

Our well-equipped facilities and exceptional excellent control throughout all stages of manufacturing enables us to guarantee total buyer gratification for Wholesale OEM China Aluminum Stepless Shear Bolt Connector, We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
Our well-equipped facilities and exceptional excellent control throughout all stages of manufacturing enables us to guarantee total buyer gratification for China Stepless Shear Bolt Lugs, We are going to initiate the second phase of our development strategy. Our company regards “reasonable prices, efficient production time and good after-sales service” as our tenet. If you are interested in any of our products or would like to discuss a custom order, make sure you feel free to contact us. We’re looking forward to forming successful business relationships with new clients around the world in the near future.
The design strength of the multi-stage shear bolt – the integral predetermined breaking points – is at the same time its decisive weakness. Each breaking point forms a discontinuity in the load- bearing thread, and the maximum clamping force can- not be achieved. A further disadvantage: The stages must be very accurately matched to the conductor of the cable- used – otherwise the bolt will break at the wrong position. Special design feature: No predetermined breaking points in the thread. This ensures the optimum thread load for any range of cross-sections. The bolt always breaks even with the surface of the clamp body – nothing protrudes, and nothing has to be filed to make the sleeve fit.

Advantages

Up to 30 % increased contact force compared with conventional type terminals

Bolt base plate for uniform friction and increased contact force

Nothing protrudes, no need for filing

Full utilisation of the thread loading for any size of conductor

No special tool needed

Smooth breakage of the shear bolt simplifies tightening process

The remains of the bolt stay on the tool and can be disposed safely
