Hot Line Clamps

Copper Aluminium Hot Line Clamp

Description:
*Hot Line Clamps are live line tools compatible for distribution tap connections.Bronze Alloy and Aluminum Alloy castings offer high strength, corrosion resistance, and conductor compatibility.

*Extended jaw width means excellent conductor contact, reduced joint temperature, minimal conductor cold flow and reduced twisting of the conductor during installation.

*Spring loaded feature compensates for cold flow and offsets tightening torque vibrations.

*Forged eye bolts provide corrosion free strength and uniformed expansion under loading.

*The side positioned tap connection prevents possible corrosion of conductor or clamp on bimetal connections.

*Successful Current Cycle testing per ANSI C119.4 provides assurances that the MPS hot line clamp will withstand the ampacity of a properly installed       connection.

For Aluminum and ACSR conductor.
• Designed for standard “hot stick” application.
Material:

Body and Keeper – Aluminum Alloy
Eyebolt – Bronze Alloy – Tin Plated
Eyestem – Bronze Alloy, Forged or Stainless Steel
Spring (on eyestem) – Stainless Steel
